Kenwood

DMX6523S Monitor with Receiver 6.8" Digital Multimedia Receiver

DMX6523S Monitor with Receiver 6.8" Digital Multimedia Receiver

DMX6523S

Dhs. 999.00 AED
Dhs. 999.00 AED
Sale Sold out
Tax included. Shipping calculated at checkout.
  • Authorized Seller
    Authorized Seller
  • Flexible Returns
    Flexible Returns
  • 100% Genuine Product
    100% Genuine Product
  • 2 Years
    2 Years Warrenty

Upgrade your car's entertainment system with the DMX6523S Monitor with Receiver. Its 6.8" WSVGA display with capacitive touch panel provides a clear view and easy navigation. Enjoy wired and wireless Apple CarPlay, Android Auto™, and wireless mirroring for iPhone or Android devices. With 13 band EQ and digital time alignment, you can customize your sound. Stay connected with built-in Bluetooth and utilize the rear view camera input with parking guidelines for added safety. Its short chassis design allows for flexible installation options.

it Monitor
Section		 Picture size 6.8 inches (diagonal) wide
Display system TN LCD panel
Drive system TFT active matrix system
Number of pixels 1,843,200
1024H x 600V x RGB
Effective pixels 99.99%
Pixel arrangement RGB striped arrangement
Back lighting LED
USB I/F
Section 		 USB Standard USB2.0 High Speed
Connector Type-A
File System USB SW update: FAT32
USB Playback: FAT32/ exFAT/ NTFS/ FAT16
Maximum Power Supply Current DC5V(DC logo) 2.1A
D/A Converter 24 Bit
Audio Decoder MP3/ WMA/ OGG/ AAC/ WAV/ FLAC
Video Decoder MPEG1/ MPEG2/ MPEG4/ H.264/ MKV/ WMV
Wi-Fi
Section		 Frequency response 192k Sampling 20 - 20,000 Hz
96k Sampling 20 - 20,000 Hz
48k Sampling 20 - 20,000 Hz
44.1k Sampling 20 - 20,000 Hz
Total harmonic distortion 1kHz 0.20%
Signal to Noise ratio 75dB
Dynamic range 93dB
Wireless LAN Standards IEEE 802.11 a/ n/ ac
Frequency Range 2.4GHz -
5GHz 5.745～5.825GHz
Channels 2.4GHz -
5GHz 149ch
Transfer rates (MAX) 11a:54 Mbps / 11n:150 Mbps / 11ac:433 Mbps
Output Power 5GHz/SISO 13.78dBm
Bluetooth
Section		 Bluetooth Specification Version Bluetooth V5.0
Frequency 2.402 – 2.480 GHz
RF Output Power (E.I.R.P.) -1.73 dBm (AVE), Power Class 2
Maximum Communication range Line of sight approx.10m
Audio Codec SBC / AAC
Multi Profile Support Multi Profile
Profile HFP(Hands Free Profile) 1.7
SPP(Serial Port Profile) 1.2
A2DP(Advanced Audio Distribution Profile) 1.3
AVRCP(Audio/Video Remote Control Profile) 1.6
PBAP(Phonebook Access Profile) 1.2
FM Frequency range (Frequency step) 87.5 - 108 MHz (50kHz)
Usable sensitivity 5dBuV
S/N:30dB 5.1dBμV/75Ω
Quieting sensitivity
DIN S/N:46dB
Frequency response(±3.0dB) 30Hz - 14kHz
S/N Ratio(dB) 50dB (MONO)
Selectivity
Stereo separation 35 dB (1 kHz)
AM Frequency range (Frequency step) 531 - 1611 kHz (9kHz)
Usable sensitivity 99μV (40 dBμ)
Video Color system of external video input NTSC / PAL
Rear view camera input level (RCA) 1 Vp-p / 75 Ω
External video input level (RCA, AV-In) -
Video Output level (RCA) 1 Vp-p / 75 Ω
Audio Maximum Power (Front & Rear) 50W x 4
Full Bandwidth Power (Front & Rear)
(at less than 1%THD)		 22W x 4
Output frequency band 20 - 20,000 Hz
Preout level (V) 2.5 V / 10 kΩ
Preout impedance (Ω) 100 Ω
Speaker Impedance (Ω) 4 - 8 Ω
Equalizer 13 Band
Band Frequency 62.5/ 100/ 160/ 250/ 400/ 630/ 1k/
1.6k/ 2.5k/ 4k/ 6.3k/ 10k/ 16k Hz
Level -09 - +09 (-9dB - +9dB)
Q -
HPF Frequency Through/ 30/ 40/ 50/ 60/ 70/ 80/ 90/
100/ 120/ 150/ 180/ 220/ 250 Hz
Slope -6/ -12/ -18/ -24 dB/Oct.
Gain -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB
LPF Frequency 30/ 40/ 50/ 60/ 70/ 80/ 90/
100/ 120/ 150/ 180/ 220/ 250 Hz/ Through
Slope -6/ -12/ -18/ -24 dB/Oct.
Gain -8/ -7/ -6/ -5/ -4/ -3/ -2/ -1/ 0 dB
General Operating voltage 12V DC car battery
Installation Dimensions W x H x D
Main Unit Installation size W x H x D 178 x 100 x 85.7 mm
Weight Main unit 1.03 kg
(Including Trim plate)
